Chittagong Sea Port, Information, Facilities & Requirements.

Chittagong ( renamed as Chattogram) is the prime port of Bangladesh. Most of shipping calling at this port.  Shipowners need to know more about this port facilities, documentation required to call at this Port. In order to operate  commercial vourage in Bangladesh maritime port, shipowners/ managers should have detail updates on crew change, documenation, OPA services, agency operation and cargo/ marine survey. Panocean team is pleased to update all with below listed information, however, if there is any specific requirements, please feel to raise us at info@panoceanbd.com

We  have also listed the documentation required for any vessel calling at Chittagong and Mongla port, mostly required by Master of vessel.



PORT COVERAGE & FACILITIES

Chittagong is considered as the prime maritime port of Bangladesh. Chittagong is also a commercial city of Bangladesh

BANGLADESH COVERS AN AREA OF

147,570 sq km, a little more than the size of Greece. It extends from 20°34N to 26°38N latitude and from 88°01E to 92°41E longitude. Maximum extension is about 440 km in the E-W direction and 760 km in the NNWSSE direction. The country is bounded in the south by the Bay of Bengal. Although Bangladesh is a small country, the length of the coastline is more than 580 km. Chittagong port is the premier port of Bangladesh, located 15km from the open sea. The port is situated on the banks of the Karnaphului River. The port limit of Chittagong port outer anchorage is bounded by area with radius of 5.6 nautical miles( on the west side) from Patenga light beacon at position Lat. 22 13.54 N long, 91 48.2 E . All climatic/hydrographic information relating to CPA( Chittagong Port Authority) outer anchorage is being well documented and promulgated by various nautical publications. CPA anchorage area is divided into three areas which follow-
Anchorage A: the northernmost anchorage for vessels of more than 10 meters draught.
Anchorage B: in between anchorage “A” and “c”, for vessel’s scheduled to enter the karnaphuli river within 24 hours. Anchorage C: the southernmost anchorage for lightering vessels and other not scheduled to enter within 24 hours.

Anchorage C: the southernmost anchorage for lightering vessels and other not scheduled to enter within 24 hours.

DRAUGHT LIMIT

From Anchorage to Jetty Berth need approx 2 hours duly compulsory piloting by Port Pilot. Vessels drawing a draught of fewer than 8.5 m usually approaches to Chittagong outer anchorage directly at any time. Vessels drawing draught between 8.5m to 9.5m also approach to the outer anchorage directly depending on the time of arrival and height of the tide. However, vessels drawing draught over 9.5
m usually wait for the rising tide to approach Chittagong outer anchorage if arrives in the falling tide.

DENSITY OF WATER

The density of water varies at each turn of the tide which is semi-diurnal with prominent diurnal effect. It is therefore advisable that the masters check. That density of water at the CPA outer anchorage.

Specialized Services for ship owners, charterers & managers

Cargo discharge supervision and Live Reporting

Ship spares inspection, export, and customs clearance

WEATHER CONDITION

The weather in Bangladesh is largely governed by the monsoon. The prevailing wind directions are from south to southeast during the month of April
through September. After taking easterly direction for a while, The wind turns to the northerly and northeasterly directions, The latter prevails from November to January. During the month of February and March, winds turn via westerly direction back to the transition periods between monsoon and season in May, October and November, extreme of inclement weather like cyclones often occur with wind velocity in excess
of 30 knots. The waves are generally low showing distinct relation with the wind. The waves period vary between 3-4 seconds of waves of about 0.5 meters and about 6 seconds for waves of 2 meters.
During the months May to October, freshets are expected. Freshets are caused by the normal velocity of flow of EBB tide augmented by flow of additional volume of water that drains into the river Karnafully from the catchment areas. Freshets are
expected when rainfall intensity reaches 200 mm in 24 hours.

Complete Shipping Support at Chittagong Port

OPA, Port Agency, Crew Change, Logistics Support at Chittagong Port.  24/7 Support Team :

info@panoceanbd.com

Looking For the documentation list REQUIRED For Vessel Calling at Chittagong Port.

More Information Releated to Chittagong Port and Support Services

Free Consultation.

FAQ

Get In Touch .

Phone:

+88-01824923983

Email:

info@panoceanbd.com

Skype

ctgshipping

Chattogram

Port  Limit

A. To the Sea :

(a) The entrance to the river with Patenga Beacon as centre if an arc is drawn seaward with a radius of 7 nautical miles till intersects the Coastline in Position Lat : 22° 20.4′ N Long : 091° 45.4′ E in the North and Lat : 22°7′ N Long : 091°50.5′E in the South, the area enclosed within the extremities of the arc;

(b) in addition to sub-clause (a), the extended seaward limit of the Port shall be as follows :
(i) North Sector: An area enclosed by joining the co-ordinates Lat: 22° 40.30′ N Long 091° 33.00′ E at Domkhali, Sitakunda, Lat: 22° 38.50′ N Long: 091° 30.00′ E at 2.90 NM seaward west of Domkhali, Sitakunda, Lat: 22° 30.00′ N Long: 091° 37.00′ E at 4.5 NM seaward west of Kumira, Lat: 22°19.30′ N Long: 091° 40.00′ E at 5.3NM seaward west of Kattoli and Lat: 22° 19.30′ N Long : 091° 43.10′ E at 2.0 NM seaward west of Kattoli intersecting 7 nautical miles radius arc from Patenga beacon at North;
(ii) South Sector: An area enclosed by joining the co-ordinates Lat: 21° 30.00′ N Long 091° 52.00′ E at Sonadia Island, Lat: 21° 30.00′ N Long: 091° 40.00′ E at 9.5 NM seaward west of Sonadia Island, Lat: 22° 06.90′ N Long: 091° 40.00′ E at 9.7 NM seaward west of Gohira, Lat: 22° 06.90′ N Long: 091° 45.80′ E at 5.5 NM seaward west of Gohira intersecting 7 nautical miles radius arc from Patenga beacon at South and including Kutubdia Channel;

B. (a) A line drawn across the River Karnafuli in a North 39°-30′ West (true) direction from a masonry pillar situated 1½ mile above the railway bridge at Kalurghat on the left bank of river in the village Kadurkhil, to a pillar situated on the right bank of the river in the village of Guzara-Noapara;
(b) A line drawn West (true) across the River Halda from a masonry Pillar situated on the left bank of river ¾ mile above the mouth in the right bank of the river in the village Mauhara;

C. To the North :
A line drawn West (true) to a distance of 1/10th miles towards land from the boundary Pillar whose latitude is 22°-15′-28″ North and longitude is 91°-46′-49″ East, in the village Patenga;
D. To the South :
A line drawn West (true) to a distance of 1/10 miles towards land from the boundary Pillar whose latitude is 22°-9′-5″ North and Longitude 91°-49′-29″ East, in the village Pourgapara.
2. These limits include so much of the River Karnafuli, the shore thereof as lie within 50 yards of high water mark at ordinary spring tides.
3. These limits also include docks, wharves, quays, stages, jetties, piers, ware-houses, sheds, railway line and yards within the limits of the boundary area and such area outside it as shown by boundary piliars on Plan No. 50 of the Port Commissioners.





Loss Prevention for Chattogram, Mongla and Payra Ports.

Navigation Support at Kutubdia, Port Captain, Pilotage.

Seasonal winds, Seas & Swell,  congested anchorage Area, comparatively small area etc are concerns for any shipowners. Need more info or 24/7  Pilotage support, please email at info@panoceanbd,com,

Email:

info@panoceanbd.com

Skype

ctgshipping

Bunker, Tanker & Container | Independent Agent

Agency Service at Maritime PORT

Crew Sign On/ Off Charges

a) Our agency wing charge USD100 per person for crew sign-on/ off formalities ( port, customs, immigration formalities). Normally it takes one working day to process crew change formalities. Weekend holidays are on Saturday and Sunday.
b) Hotel charge depends on a single person or dual occupancy basis and quality of Hotel standard. It may range within US$50.00 to US$150.00 ( except five-star hotel).
c) Food charge per person may range within US$50 to US$150 ( standard meal 3 times), subject to hotel standard ( except 5-star hotel and hard drinks).
d) Recommended local airlines are NOVO AIR, US BANGLA, Bangladesh Biman. Local airport at Chittagong (Shah Amanat) International Airport. Transit time from Dhaka to Chittagong by air is 50 min. Airfare range  within USD40.00 to US$90.00

Estimated Port DA

Coast To Coast, the local correspondents,  have developed a secure website link ( online calculator), which can help you to calculate the Port DA for any vessel within seconds. Just need to mention  GRT, NRT, DWT, TPC, Cargo quantity and estimated discharge rate.  Please email us at info@panoceanbd.com for the encrypted link.

Bunkering at Chattogram and Mongla

IFO-180 CST, MGO is available at Chittagong. It is recommended to use JAMUNA for bunkering. Local bunkering companies are available. Bunker supplier should not be allowed to deal with the vessel’s official’s prior supply of bunker. Dip sample should be taken during bunkering. The qualified and honest surveyor should be used during bunkering and surveyor should not board with bunker supplier barge.

Why Shipowners require PROTECTIVE AGENTS

Discharge port agents are appointed by Charterer and nominated by a receiver. Shipowners need assistance at Chittagong( Chattagram as renamed), Mongla or even Payra to protect the interest. As in most of cases, a vessel may face the following situation/ incident and require professional support:

  1. Collision, grounding or wrongful navigation by pilots
  2. Delay in discharge or placement of lighter vessel or berthing
  3. Communication gap with voyage charterer’s or receiver’s nominated agents
  4. Discharge without production of OBL and delivery to ultimate receivers
  5. Excessive port DA and manipulated SOF to protect the interest of cargo receiver
  6. Damage to mother vessel by lighters and excessive repair charges
  7. Wrongful treatment for injured crews, complication during crew change etc.
  8. In time berthing arrangement or sailing arrangements.
Maritime Ports in Bangladesh | Chittagong, Mongla, Payra

The Chittagong port is the biggest seaport of Bangladesh. It is located by the estuary of the Karnaphuli River in Patenga, Chittagong. Recently, Chittagong city has been renamed as Chattagram. Earlier, 8.5m was the permissible draft to enter the inner harbor. Now Port allow berthing of ships with a draught of up to 9.5 meters during high tide.

Mongla Sea Port is the second largest and most Eco-friendly port of Bangladesh. It is located on the southwestern part of the country, at the confluence of Pussur River and Mongla Nulla. Approximately 71 nautical miles (131 Km.) upstream of the Bay of Bengal. For berthing at inner harbor, this port allows vessels with a draught of up to 7-8 meters.

Payra Port, the small seaport in southern Bangladesh, sits on the west bank of Rabnabad channel at the confluence of Galachipa-Tetulia river. Payra Port started operation in August’2016 with ship-to-ship cargo transfer, though on a limited scale. It is expected that the first phase of dredging for this port will be completed by 2020. Then vessels with a draught of up to 11 meters will be able to berth at the seaport during high tide time. Bangladesh is now the concern for a deep-sea port and had granted a contract to Japan to build a deep sea port at Matarbari, which is just 25 kilometers away from Chittagong.

LPG Information for the Maritime port of Mongla

As regards LPG vessel’s calling at the Maritime Port of Mongla, please note, there are eight LPG terminals in operation as of now and a numbers of terminals are at their final stage of construction.  Most of the terminals are subjected to frequent siltation and regular dredging is required to keep them operational. The available max depth at the terminal must be verified before any vessel fixed for a terminal.Max Draft for entering port: 7.0 M to 8.0 M depending on daily rise of tide, as Mongla Port is a Tidal Port and all arrival and departure takes place during Flood tide.  Max berthing Draft….Need more info, email us.

Panocean Limited, registered with Joint Stock Company of Bangladesh, Port and Customs Approved member of Bangladesh Shipping Agents Association. We can act for any shipowners or charterer looking for an independent agent to declare vessel at Port, arrange immediate berthing or discharge operation, ensure SOF for vessel’s interest and delivery of cargo with BL/ LOI as per Principals instruction. In addition, we also provide FREE consultation support for Port DA, Weather Condition, Berthing Line Up at Port, safe navigation, etc.

Pre-Arrival Documentation

Pre-arrival docs required to send by email:-
——————————————-

(1) ship particulars,

(2) updated crew list,

(3) stowage plan,

(4) last port clearance,

(5) crew vaccination statement

(6) CLC certificate copy,

(7) Certificate of registration,

(8) Maritime declaration of health,

(9) Last 10 ports of call,

(10) Last 30 days all crews travel information

(11) No EBOLA virus on board crew officers/members statement

(12) Ship’s Hull anti-fouling paint is free from harmful organotins
“organotin tribuline (TBT)”

(13) No ZIKA Virus on board crew officers/members statement.

(14) Last Port State control Inspection certificate

(15) Ballast water management certificate

(16) Wreck removal certificate

(17) PNI certificate

(18) Load Port Survey report

Also please prepare & keep ready following A, B & C mentioned documents (all
in original), which will collect by our boarding agents for inward
formalities.

“A”  ARRIVAL DOCUMENTS:-
————————

01.    NOTICE OF READINESS             :   02 COPIES

02.    SHIP’S ARRIVAL REPORT           :   02 COPIES

03.    SHIP’S PARTICULARS              :   02 COPIES

04.    CREW LIST                       :   10 COPIES (out of which 5 copies
with arrival date for arrival formalities and balance 5 copies without date
for sailing formalities).

05.    CREW VACCINATION LIST           :   04 COPIES

06.    CREW PERSONAL DECLARATION       :   04 COPIES

07.    SHIP’S PROPERTIES.              :   04 COPIES

08.    ENGINE STORE DECLARATION        :   04 COPIES

09.    DECK STORE DECLARATION          :   04 COPIES

10.    SALOON STORE DECLARATION        :   04 COPIES

11.    STATIONERY DECLARATION          :   04 COPIES

12.    MEDICINES DECLARATION           :   04 COPIES

13.    CURRENCY DECLARATION            :   04 COPIES

14.    PROVISION DECLARATION           :   04 COPIES

15.    BOND STORE DECLARATION          :   04 COPIES

16.    MARITIME DECLARATION FORM       :   02 COPIES

17.    STOWAGE PLAN                    :   04 COPIES

18.    CARGO MANIFEST                  :   04 COPIES

19.    NIL LIST                        :   04 COPIES

20.    STATEMENT OF CERTIFICATE LIST FOR OFFICER’S
       ON BOARD WITH GMDSS (NO., ISSUE DATE, VALIDITY): 02 COPIES

21.    STATEMENT OF VESSEL’S CERTIFICATE LIST WHICH MENTIONED BELOW IN “B”
SHIP’S DOCS

       (NO., ISSUE DATE, VALIDITY)     :  02 COPIES

22.   LAST PORT CLEARANCE            :  01 COPY.

– “B”  SHIP’S CERTIFICATE / DOCS REQUEST TO SEND BY E-MAIL :-

1. Ship’s Registry Certificate
2. Load Line Certificate
3. Safety Construction Certificate
4. Safety Equipment Certificate with Form “E 5. Safety Radio Certificate
with Form “R”
6. I O P P Certificate with Form “A”
7. I A P P Certificate
8. I S P P Certificate
9. Ship’s Station/Mobile License/Radio License 10. Minimum Safe Manning
Certificate 11. Safety/Ship Management Certificate (SMC) 12. Document of
Compliance (DOC) 13. International Ship Security Certificate (ISSC)
14. Continuous Synopsis Record Certificates(CSR)
15. Emergency Position Indicating Radar Beacon (EPIRB) 16. Last Port State
Control Inspection Report (PSC) 17. Civil Liability for Bunker Oil Pollution
Damage (CLC) 18. Ballast Water Management Certificate 19. The Removal of
Wreck 20. Ship Sanitation Control Exemption Certificate

– “C”.  Officer/Crew Certificates List for Pre-Arrival :

– Master : COC + COE/COR + GMDSS + FLAG ENDORSEMENT (COC & GMDSS)
– Chief Officer : COC + COE/COR + GMDSS + FLAG ENDORSEMENT (COC & GMDSS)
– Second Officer : COC + COE/COR + GMDSS + FLAG ENDORSEMENT (COC & GMDSS)
– Third Office : COC + COE/COR + GMDSS + FLAG ENDORSEMENT (COC & GMDSS)
– Chief Engineer : COC + COE/COR + FLAG ENDORSEMENT
– Second Engineer : COC + COE/COR + FLAG ENDORSEMENT
– Third Engineer: COC + COE/COR + FLAG ENDORSEMENT
– Fourth Engineer : COC + COE/COR + FLAG ENDORSEMENT
– Electrician : COC + COE/COR + FLAG ENDORSEMENT
– Ship’s Cook Certificate
– All Crew COC/Navigation Watch Rating Certificates

Also please fill up attached file (1st & 2nd page) and send to us by email.

USEFUL INFORMATION . :

1)      CHITTAGONG PORT SECURITY LEVEL : 1.

2)      FIRST VESSEL HAVE TO ARRIVE/ANCHORAGE AT KUTUBDIA FOR  DISCHARGING
SOME
QUANTITY OF CARGO FOR ENTERING AT ALPHA ANCHORAGE FOR DISCHARGING BALANCE
QUANTITY  OF CARGO.

3)      AT KUTUBDIA (BRACKISH WATER) ANCHOR POSITION WILL BE AS FOLLOWS :-

Lat – 21 – 52.1 N
Long – 91 – 48.1 E

Lat – 21 – 52.116 N
Long – 91 – 47.693 E

Lat – 21 – 50.387 N
Long – 91 – 47.261 E

You can also try below coordinates as usually availed by other masters.

Lat – 21-51.299N
Long- 91-47.268E

Lat- 21-53.45N
Long- 91-48.59E

Lat-21-50.23N
Long- 91-47.19E

LAT 21-48.67N,
LONG- 091-47.72E

However, Pls follow latest version BA Charts.

4)      PILOTAGE IS NOT COMPULSORY BUT HIGHLY RECOMMENDED BY PORT AUTHORITY
.

5)      PLEASE BE INFORMED THAT DURING ROUGH WITH  SWELL & WIND  YOU ARE
REQUESTED TO TAKE NECESSARY PRECAUTION BY YOUR SHIP’S CREW MEMBERS & ALSO
INSTRUCT STEVEDORES SUPERVISOR ACCORDINGLY  TO AVOID ANY DAMAGES TO THE
SHIP’S PROPERTY. ALSO ADVISED TO TAKE SPECIAL CARE WHEN L/VSL WILL GO
ALONGSIDE AND WHILE WILL BE CAST OFF FROM ALONGSIDE ( DOCKING  & UNDOCKING
MANEUVERING ) FROM THE M/VSL. ON THE OTHER HAND WHENEVER WEATHER CONDITION
BECOME ROUGH, STRONG WIND & FOUND HEAVY SWELLING THEN PLEASE  ADVISE MASTER
OF THE L/VSL  TO CAST OFF IMMEDIATELY TO AVOID ANY POSSIBILITY OF DAMAGES.
T4 MASTER OF THE  M/ VESSEL REQUESTED TO ENSURE TO TAKE SUCH PRECAUTION.
“”…..ALTHOUGH LIGHTERS ARE  AVAILABLE  HAVING FITTED SUFFICIENT TYRE
FENDERS , BUT  MASTER IS REQUESTED TO TAKE ADDITIONAL   PROTECTIVE MEASURES
BY ARRANGING BIG FENDERS TO PLACE/RIG WHILE LIGHTERS APPROACHING AND MOORING
ALONGSIDE/CAST OFF PARTICULARLY DURING BAD WEATHER, HEAVY SWELLING AND ROUGH
SEA CONDITIONS  TO AVOID ANY POSSIBILITY OF DAMAGES……””

6)      AFTER ARRIVAL KUTUBDIA ANCHORAGE MASTER TO  ADVISE GPS POSITION TO
PORT & AGENT IMMEDIATELY

7)       VESSEL WILL CONTACT PORT CONTROL OVER VHF CHANNEL 12 OR CHANNEL 16
WHILE VESSEL WILL PROCEED FROM KUTUBDIA TO ALPHA ANCHORAGE.

8)      VESSEL WILL START FROM KUTUBDIA AT LEAST 3 HRS BEFORE TOP OF THE
HIGH WATER  AT ALPHA ANCHORAGE TO DROP HER ANCHOR AT ALPHA .

9)       PLEASE DO NOT CROSS THE BOW OF OTHER VESSEL AT CLOSE RANGE OF
DISTANCE FOR AVOIDING DRIFTING AND COLLISION WITH THE VESSELS AT ANCHOR.

10)    PLEASE KEEP SAFE DISTANCE WHILE VESSEL DROP HER ANCHOR  CONSIDERING
STRONG WIND AND CURRENT.

11)   MASTER IS  REQUESTED TO DROP INTO WATER  9 OR MORE  SHACKLES  OF CHAIN
FOR AVOIDING DRAGGING BEING STRONG CURRENT PREVAILING THIS ANCHORAGE.

12)    THE SHIP’S CREW/OFFICER  MUST BE CAREFUL DURING TIDE CHANGING TIME &
CONSTANT VIGILANCE   ON BRIDGE FOR AVOIDING ANCHOR DRAGGING OR DRIFTING.

13)   MASTER IS ALSO REQUESTED TO MAINTAIN CONSTANT WATCH FORECASTLE AND
POOP OF THE VESSEL  TO AVOID PILFERAGE AND THEFT.

14)    PLEASE FOLLOW PFSO DETAILS: NAME : LT CDR M NEZAM UDDIN C,BN

MOB.NO.880 1733 228266

TEL: NO.880-031 2517386,2522200-29(EXT-2018)

VHF CH.16.

15) PLEASE ALSO FOLLOW BA CHART NO. 84 FOR APPROACHING FROM KUTUBDIA  TO
ANCHOR THE SHIP AT ALPHA ANCHORAGE.

Circulars : Chattogram Port Authority Circular. by Ministry of Shipping dated 21st Jan 2019

LIGHTERING OF CARGO AT CHITTAGONG ANCHORAGE AT MONSOON SEASON

Panocean pleased to update on STS operation. Lightening of cargo at Chittagong outer anchorage becomes relatively more difficult with the onset of monsoon and the period from May to October is considered as the monsoon. At any time within this period, rough sea and inclement weather is a common feature of the weather condition and often the weather condition deteriorates so abruptly that incidents, such as the one under consideration, becomes unavoidable. During this period, lighter vessels fastened alongside mother vessel experience heavy rolling and pitching often causing hard scarping, bendings and indentations to the mother vessels railing and hull. This is despite the fact that generally, the lighter vessel has fendering arrangements consisting of old mooring ropes wrapped around wooden spars often used or second-hand tires from automobiles are also used as fenders. Insofar as damages to mother vessel are concerned, top shell plate of the forecastle deck, bulwark gunwale, bulkhead (Both port and STBD side), brackets underneath and horizontal to gunwale and the hull, in general, are the areas of the mother vessel prone to contact damages caused by lighters situation worsens often because of the fact that generally the lighter vessel do not have winches fore and aft in order to heave up berthing ropes quickly. It is true that lightering at Chittagong outer anchorage during the period of yearly monsoon is difficult but it is only during some of seasonal the period. If adequate preventive measures are taken, collisions of nature under consideration can be avoided. However due consideration to the involved facts and circumstances leading to a particular incident are to be given. Usually the freeboard of a lighter vessel is much higher than that of the mother vessel when the former approach the latter the reason being that the lighter vessel is in light condition while the mother vessel is fully loaded to avoid contact damage in such in a situation a close communication/coordination between both the lighter and mother vessel involved are needed.

Anchorage Grounds

The Port has the following recommended Anchorage Grounds:
ANCHORAGE “A” is formed by extending 2 (two) lines up to Port limit, one (first) having bearing 337045′ and the other (2nd) 310030″ from the point having lat 22012’30″N and long 91047’00″E.
ANCHORAGE “B” is formed in between 2nd and 3rd line having bearing 2340 extended up to Port limit from the previous point.
ANCHORAGE “C” is between 4th and 5th line having bearing 234) & 157) respectively, extended up to Port limit from a point of lat 22012’00″N long 91047’12″E.
The space between 3rd and 4th line is prohibited anchorage. “A” Anchorage is for vessels over 30ft. draft. “B” Anchorage is for vessels entering the Port within 24 hours. “C” Anchorage is for vessels lightening and other vessels not scheduled to enter the Port within 24 hours.

ADMIRALTY CHART

The following Navigational Aids guide ships to approach the Port of Chittagong. REFERENCE
a) Admiralty Chart No. 84″ Approaches to the “Karnafuli River” Bay of Bengal Folio.
b) Admiralty Chart No. 859″ “Elephant poin to Matla River” Bay of Bengal Folio.
c) Bay of Bengal Pilot.







CLEARANCE OF CARGO FROM THE PORT

This port is connected with the hinterland by Bangladesh Railway, the inland Waterways through the Bay of Bengal and the Road network. Clearance of Dry cargo from the Port by the three modes of transport viz. Rail, Road and River, were approximately 4,93,578 M.T. 36,59,859 M.T. & 8,96,744 M.T. respectively during the period 1994-95.

CPA’S JETTY BERTH


There are 15 Jetties of which 13 are provided with shore cranes and Railway tarcks, 11 are provided with Transit sheds. Vessels upto 185.91 M (LOA) may be berthed at a single cement concrete main Jetty. Backyard facilities are there for handling container/container cargo vessels.

COMPANY VALUES

Navitation Support at Chittagong

Navigation Information

Vessel need adequte information as regards navigation information for Chittagong to avoid any unwanted incident. READ MORE

Pilotage Services

Seasonal winds, Seas & Swell,  congested anchorage Area, comparatively small area etc are concerns for any shipowners. READ MORE

Sourcing Ship Spares

Bangladesh’s Chittagong ship breaking site is made from 80 separate yards. Spares are sourced from yard based on requirements. Read More.

Navigation at Anchoarge

Vessel need adequte information as regards navigation information for Chittagong to avoid any unwanted incident. READ MORE

Pilotage Service at Kutubdia

Seasonal winds, Seas & Swell,  congested anchorage Area, comparatively small area etc are concerns for any shipowners. READ MORE

Ship Spares from Yards

Bangladesh’s Chittagong ship breaking site is made from 80 separate yards. Spares are sourced from yard based on requirements. Read More.

24/7/365 Support at Chittagong, Mongla, Payra. Inquiry & Need to reach us: Connect Now by Email or Connect Now Over Phone . Chat Now at WhatsApp

Relevant navigational information’s as per Chittagong port regulations are given below which need to be followed for safe navigation:

SAFE NAVIGATION

1. SHIP MOVEMENT generally commences
about 4/5 hrs. before the day’s High water.
2. MOVEMENT OF VESSELS on the day’s
marked AM & PM depend upon draught,
the rise of tide, availability of berth & available
daylight. All concerned are to consult the
Harbour Master 24 hrs. before the
movement. In such cases, Ship’s with day’s
maximum draught will be handled during
AM or PM depending on the availability of
day light hours.
3. DURING the spring tide/freshets/foul
weather vessels under 7 knots will not be
normally handled and all such vessels will

be classed at GRADE-II for operational
purposes and shall be handled
conveniently. Agents of such vessels are
required to consult the undersigned well in
advance.
4. The port will not be responsible if the
declared draught are reduced due to
conditions arising out of freshet effect or
other causes which cannot be forecast.
Owners & Owners agent are advised to
consult the undersigned regarding deep
draught vessels in advance.
5. Vessels entering or leaving port must have
full power on main engine & deck
machinery’s, both anchors with full length
of chain must be available for use at all
time.
6. All vessels entering/leaving port shall
display their signal letters.
7.
a. Ship Masters are required to anchor clear of
the “PROHIBITED ANCHORAGE”.
b.Ship Masters must not anchor their vessels
near the River entrance.
c. Ship Masters must manoeuvre with great
care while embarking/disembarking pilots.
d.Pilot ladder as per regulation must be
provided.
e. Ship Masters must note that the strong tidal
conditions prevail at outer anchorage and
utmost
f.care must be taken while manoeuvering
anchoring or heaving up anchors.
g. Crossing of the bow at close range shall never be
attempted.
8. Ship master are advised in their own
interest to maintain a watch on the Fo’castle
and poop while the vessels are at outer
anchorage.

9. Ship master must send their ETA,
DRAUGHT and other particulars to the
undersigned well in advance.
10. All ships in port to provide requisite “RAT
GUARDS” in the mooring ropes.
11. Ship master on arrival and prior to
departure, are required to ensure that the
vessels draught marks are clearly visible for
Pilots to read the draught correctly.
12. Ship master are required to ensure that no
major chipping of ships side is carried out
while their vessels are in port.
13. UNDUE “SMOKING” from the vessels
within the port area is strictly prohibited.
14. DISCHARGING of water on the jetty and
listing of vessels while alongside is strictly
prohibited.



SAFE NAVIGATION..cont

15. Karnafulli being tidal river, it is essential for
vessels entering port to have six good ropes
(HAWSER & WIRE) forward and similar
six ropes aft. for mooring purpose.
16. IN AN EMERGENCY, Signal for Tug in
port consist of 4 prolonged blasts on the
whistle.
17. IN AN EMERGENCY, the following may
be contacted on PHONES:
18. VHF(R/T) watch is maintained in the Port
Administrative Building, round the clock
and the same can be contacted any time
during day or night channel-12(Frequency
156.6MHZ or Channel-16, Frequency 156.8
MHZ ) watch on 2182 KHZ is also
maintained simultaneously.
19. Ship masters approaching Chittagong road
are advised not to attempt to cross bow of
vessels at anchor/underway to avoid drifting
on them resulting probable collision in view
of the prevailing strong current at outer
anchorage. However, if it is inevitable to
cross, ship master may do so with caution

by giving wide berth to the vessels at
anchor/underway considering the minimum
a velocity of the current being 6 knots and
other marine factors.
20. When a vessel is given standby from
Radio Control for entering Port & Pilot is
on his way, it is advisable that ship master
should heave up anchor and wait for the
Pilot steaming the tide near about position,
Patenga Lighthouse bearing 045º (T)
distance 2 miles if deemed safe to do so.
21. Vessels having a container on the deck
obstructing a clear view of forwarding and or
obstructing a clear view of the starboard side
when viewed from port bridge wing and
vice versa will not be allowed to navigate
in the channel of Karnafulli River. When
considering a clear view, small craft crossing
the vessel’s bow should be taken into
account.
22. Vessels arriving for demolishing purpose
are advised to drop anchor North of Lat:
22º 16’ that is North of Alfa Anchorage.
23. Under all circumstances international
regulation for preventing a collision at sea,
1972 and as amended in 2002 to be
followed as closely as possible while
navigating within the Port limit of CPA.
24. Admiralty Chart No. 84 “Approaches to the
“Karnafuli River” Bay of Bengal Folio”,
Admiralty Chart No. 859 “Elephant point
to Matla River”: Bay of Bengal Folio.
These charts need to be considered.

D E S C R I P T I O N

The Port of Chittagong is the principal Port of the People’s Republic of Bangladesh. It is situated on the right bank of the river Karnafuli at a distance of about 9 nautical miles from the shoreline of the Bay of Bengal. River Karnafuli rising in the Lushai Hill falls in the Bay of Bengal after taking a winding course of 120 nautical miles through the districts of Chittagong Hill Tracts and Chittagong.

UPPER LIMITS

Upper limits of the river water are formed by two straight lines, one drawn across the Karnafuli River in the North by joining two pillars located at:-
Lat : 22024’33″N Long : 91054’30E and Lat : 22024’56″N Long : 91054’11″E and the other by joining the two pillars located at:
Lat : 22025’07″N Long : 91053’18″E and Lat : 22025’07″N Long : 91053’10″E These limits include so much of the sea and of the River Karnafuli and the River Halda and the area that lie within 137.162 Metre, of high water Mark at ordinary spring tide and the docks, wharves, quays, stages, jetties, piers, warehouse, sheds, railway line and yards within the limits of the bounded area and such other area outside it as included in the Schedule iii of the Chittagong Port Act. The seaward approach to the Port of Chittagong may be considered to be northwards of the 10 fathom contour in latitude 22024′ North and longitude 9103″ East: The distance to the pilot ground from the south patches shoal being 46 nautical miles on the direct course. Panocean Limited can assist at Chittagong Port.

SEAWARD LIMIT

With Patenga Beacon as center if an arc is drawn seaward with a radius of 5.5 nautical miles till it intercepts the coastline at positions:-
Lat 220 18’45” N. Long. 91046’30″E in the North and Lat 22008’13″N.Long 91050’00″E in the South, the area enclosed within the extremities if the arc will from the Seaward limit of the Port of Chittagong.

Need more consultation, calculate vessel’s Port, or need information for preparing any project proposal or there is requirements for marine/ cargo survey.

SERVICE AND FACILITIES AT PORTS

Pilotage is compulsory for ocean-going vessels. The entrance to the river is constantly changing and no vessel should attempt to enter without a pilot. Pilot boards approximately 2 nautical miles seaward of the outer Bar Buoy.
In the moderate-heavy weather, a lee must be made for the Pilot Boat. The vessel receiving a Pilot is required to wait at the pilot ground near the entrance all clear of anchor taking into consideration the effect of tide and other conditions to facilitate boarding of the pilot in good time to be able to avail of the tide for entering and berthing etc. The propelling distance from the pilot ground to the main jetties is approximately 11 nautical miles and the distance has to be covered at a variable speed in different sections of the river. Inward ships must present themselves at a pilot ground at least 3 hours before the high water to enter on a particular day. This, of course, is subject to the availability of berth and having permissible draft and length etc.

The ship movements generally commence about 5 to 5 hours before the day’s high water and the tides have been termed Day or Night taking this factor into consideration.
During the spring tide/Freshet/Foul weather vessels under 7 knots will not be normally handled and such vessels will be classed grade 2 for operation purpose. Agents of such vessel are required to consult the Deputy conservator well in advance. Masters are advised to maneuver with great care while receiving and disembarking pilots. Vessels due for entering in the next 24 hours must anchor in Anchorage B. Keep R.T. Watch at least 3 hours before the pilot boarding time and also display her signal letters.
Incoming vessels normally enter with the flood time. The normal maneuver is to snub with the starboard anchor and proceed to berth/mooring after heaving up and finally go alongside using the port anchor.

PUBLIC SECTOR JETTIES

For bulk cargoes like Wheat, Cement Clinkers, Rock Phosphates and Urea Fertilizer etc. the following Jetties are available.
(A) FOR OCEAN GOING VESSELS
1)Cement Clinker Jetty for vessels up to 167.63M.
2) Grain Silo Main Jetty for vessels up to 185.91 M. LOA.
3) T.S.P Jetty for Vessels up to 175.25M.
4) DDJ/1 & DDJ/2 Two or more vessels having total LOA 302M and having draft not more than 7.00 M may be berthed.
5) Chittagong Urea Fertilizer Jetty for Vessels up to 176M. can be loaded up to a maximum draft of 8.50 M.
6) KAFCO-1 (UREA) & KAFCO-2 (AMMONIA) Vessels having a maximum length up to 185.91M and be loaded up to a maximum draft of 9.14 M. (To be commissioned soon).

FOR COASTERS AND INLAND VESSELS

Grain Silo Lighter Jetty for inland vessels and I.W.T. Vessels/crafts.
CHITTAGONG PORT LIGHTER JETTIES
(1) L.J. NO.1 – Permanent cement concrete Jetty with 122 M. Jetty face at Sadarghat for coasters and inland vessels up to 70M. length vessels with dry cargo.
(2) L.J. No.2 – with Pontoon and shore connection (at New Mooring) for coasters and inland vessels up to 76M. With dry cargo.
(3) L.J. No.3 – with Pontoon and shore connection (Jamuna) for inland tankers and vessels up to 76M. with POL in Bulk.
(4) L.J. No.4 – with Pontoon and shore connection (Meghna) for inland tankers and vessels up to 75M. with POL in Bulk.
(5) L.J. No.5 – with Pontoon and shore connection (ITT) for inland tankers and vessels up to 75M. with edible oil in Bulk.
(6) L.J. No.6-with cement concrete Jetty (PADMA) for inland tankers and vessels up to 70M. for bulk Pol.
(7) MOORING BERTHS
1) River Mooring No.3 for ships up to 182.87 M. LOA and 7.61M. Draft with dry cargo and edible oil for overside work.
2) River Mooring No.4-with Pontoon and shore connection for vessels up to 170.67M. LOA and 9.14M. draft with edible oil and POL in bulk.
3) River Mooring No.5-with Pontoon ans shore connection for vessels up to 185.91 M. LOA and 9.14M draft with POL.
4) River Mooring No.6-with Pontoon and Shore connection for vessels up to 185.91 M. LOA and 9.14 M. Draft with POL.
5) Dolphine Oil Jetty: For vessels up to 185.91 M.LOA and 9.14 M draft for discharging Crude Oil.
6) River Mooring No. 8 for vessels up to 185.91 M. LOA and 8.0M draft with dry bulk cargo for handling through lighters.
7) River Mooring No.9-for vessels up to 185.91 M. LOA and 6.OM draft for repair of vessels. laying off.

HANDLING EQUIPMENT

(A) Shore Crane
There is 32 portal level luffing Electric cranes of 3 tons capacity each with 2 radius of 19.81 and 25M.
(B) Other Handling Appliances
Description Capacity Number Fork Lift Truck 5 Ton 7 Nos (1 at LCD) Fork Lift Truck 3 Ton 43 Nos. Mobile Crane 30 Ton 2 Nos. Mobile Crane 20 Ton 3 Nos. Mobile Crane 10 Ton 5 Nos. Mobile Crane 6 Ton 11 Nos. Heavy Tractor 25 Ton 5 Nos. Light Tractor 6 Ton 18 Nos. Heavy Trailer 25 Ton 15 Nos. Light Trailer 6 Ton 37 Nos.
Other Appliances JCBC handling attachment 7 Nos. Drum handling attachment 9 Nos. Bale handling attachment 1 Nos. Fork extension 6 Nos.

LIGHTERAGE OF CARGO

The deep draft vessels can be lightered at the Outer Anchorage http://cpa.gov.bd/. This is to be restored to for vessels of deeper draft kutubdia. Depending on the Quanram involved in lighterage T-2 Type tankers and liberty vessels are arranged on a character by the concerned Agencies from abroad or from the Bangladesh Shipping Corporation. Except the Ocean going Tankers and Vessels of Bangladesh Shipping Corporation engaged in lighterage, local lighterage, fleet consist of tankers each of approximately 1,000 tons capacity and coaster each of the capacity of 300 to 1000 tons owned by the Public and Private Sectors are deployed. Besides this country craft, each of 20 to 80 tons capacity in the private sector and steel barges each of 300 to 500 tons capacity in the public and private sectors are available to carry out lighterages work. The cargo from such lighters intended to be discharged at the Chittagong port is handled at a vacant jetty or in between the two vessels alongside the jetties. Cargo discharged into lighters at Outer Anchorage may also be directly transported to inland river ports and Mongla Port the Second international Port f the country, with prior permission of the port and Customs Authorities..

SUPPLY OF WATER, BUNKER & PROVISION

Fresh water is available at all the Chittagong Port Authority Jetties. Water is also supplied by Propelled water Barges to vessels inside Port and at the Outer Anchorage. Due to rough sea and inclement weather, water supply at the outer anchorage is affected often during Mid April to Mid October. Oil bunkers can be supplied to the vessels at the Oil Moorings. In emergent cases, Oil companies may undertake supply of Bunkers by inland tankers. Coal Bunkers are available and supplies can be obtained by the Master/Local Agents through the Assistant Controller of Coal, Chittagong. Fresh meat, fish, vegetable, milk, egg, rice, wheat, bread abd butter etc, are available for supply.

NIGHT NAVIGATION

Night Navigation vessels upto 153.00M length with draft having 0.50M less than the days permissible draft will be allowed to take berth during Night (6 pm to 6 AM) at the Jetties from J/ltoj/13, MPB/1, MPB/2, DDJ/1, DDJ/2 and CUFLJ only.
Vessels with midship bridge upto 165.00 m & Vessels with AFT. Bridge upto 153.00 M Length having 0.30m (1.ft) Less than the day’s permissible draft will be allowed to sail out during Night from j/1 to j/13, MPB/1, MPB/2, CCJ, GSJ, TSP, DOJ. DDJ/1, DDJ/2, & CUFL only.
Vessels with bridge on the BOW & vessels having containers on deck obstructing clear view of forward, will not be handled during night. Vessel will not be allowed to take berth at or to sail out from jetty no.14,15,17, RM/3, RM/5, RM/6, RM/8 & RM/9 During night.
